describe
- Conforms to standardEN 60947-5-2
- Symbol00991701
- CertificationRCM compliance mark c UL us – Listed (OL)
- CE marking (see declaration of conformity)As per EU EMC directive
- Note on materialsRoHS-compliant
- Rated operating distance1.5 mm
- Assured operating distance1.21 mm
- Reduction factorsAluminum = 0.25 Stainless steel St 18/8 = 0.7 Copper = 0.2 Brass = 0.35 Steel St 37 = 1.0
- Ambient temperature-25 °C … 70 °C
- Repetition accuracy under constant conditions0.07 mm
- Switching outputPNP
